CA-QY series

The new energy welding machine electrolyzes water into hydrogen and oxygen through electrolysis of water, connects it to a special welding gun, ignites it with an igniter, and forms a high temperature hydrogen oxygen flame to weld the workpiece; Hydrogen and oxygen burn to form water without any carbon.

PrimaX IR Pro

● Based on the redundant design of dual-infrared light source of patent, ensure more reliable and continuous gas monitoring; ● Patented probe protection shield designed to provide faster response (4 seconds) while protecting the probe; ● A typical life span of 15 years, leading industry level; ● Imported 316 stainless steel infrared probe, IP67 protection grade, and 40 ℃to + 70 ℃temperature work, apply to extreme environment requirements; ● Four highlighted leds show a high gloss filter, which is still visible in bright light; ● Equipped with optical Windows heating function to avoid rain and snow and condensation.

HP

CACL-788C-HP series special filling machine for heat pipe industry, which integrates vacuum pumping, leakage detection and medium filling, can fill R1234yf, R1234ze, R245fa, acetone, water and other media, and is applicable to all types of models in the heat pipe industry. The CA-HPG special filling gun ingeniously separates the medium from the vacuum, making the medium unable to enter the vacuum pipeline, without affecting the vacuum performance.

CR170

Ultracold gas can refrigeration temperature below 80℃, mainly used in environmental test chamber, hot and cold impact testing machine, freeze dryer, cryogenic refrigerator or freezer, blood bank refrigerators, biochemical test chamber or other cryogenic equipment. R170 and R508B is currently typical environmental cryogenic refrigerants, R170 and R508B have no damage to the ozone layer. The charging mode of ultracold gas is different from usual gas, currently the rest of the world's manufacturer of ultracold gas filling accuracy is only 100g±5g, while CACL, with many years of technology accumulation and continuous innovation, pioneered the filling accuracy 100g±2g ultracold gas charging machine, raise the industry standard once again. CA-788C-CR170 has been designed to charge R170, R508B or other ultracold gas. Charging volume up to 999g, charging precision 100g ≤ ±2g.

CR717

CA-788C-CR717 series Ammonia water charging machine, systemic anti-corrosion design, stainless steel pipe, prevent leakage and corrosion. Equip pulse resolution 1/10g precise VIS Ruby flowmeter and CACL intelligent double class balance cylinder. Charging precision 100g±0.5g，100g outside±0.5%, charging volume 20-9,999g and charging speed is 60-100g/s. CACL mature digital technology makes Ammonia water charge much safety and easy.

CR744

CA-788C-CR744 series carbon dioxide charging machine, can charge CO2 or other gas refrigerants. Due to charging mode of gas refrigerants is different from usual refrigerants, currently the rest of the world's manufacturer of cryogenic refrigerant filling accuracy is only 100g±5g. 788C-CO2 series adopt CACL subcritical condition charging technology, equip CA-6170 charging gun, make the charging precision up to 100g ≤ ±2g, 100g outside≤ ±2%, raise the industry standard greatly.

T4

CA-788C-T4 series double gun double system refrigerant dispenser can be used to fill HCFC, HFC series mainstream refrigerants such as R134a, R513a, R22, R404A, R406A, R410A, etc. It is suitable for refrigerant filling of various refrigerators such as drinking fountains, refrigerators, freezers, heat pumps, etc. The T4 series is equipped with a two-way charging system (two-way IDB intelligent two-stage balancing cylinder, two-way CA-5AG rear ejector pin charging gun, two-way pure pneumatic high efficiency booster pump, two-way ruby flowmeter), which realizes the online charging of dual refrigerant, greatly improves the production efficiency and meets the mixed line production requirements.

T5

CACL-788C-T5 series double charging system high-speed refrigerant charging machine has been design to charge R22, R407C, R410A or other HCFC, HFC refrigerants and to be used in any type of cooling unit assembly line (central air-conditioning, commercial air conditioning, water chiller unit etc.) performing evacuation, leak tests and refrigerant charges. T5 series double system run independently, which means you can charge two different refrigerants simultaneously. Thanks to CA-7AG high-speed charging gun, S5 series not only has faster charging speed, also make the charging process more smoothly. T5 equip CA-CM4 efficient booster pump and ULVAC high power vacuum pump, ensure refrigerant pure liquid charging in a high-pressure environment. The fastest charging speed ≥180g/s, the biggest charging volume is 299,999g (Extensible), and all can customize according to your requirements.

S4

CACL-788C-S4 series refrigerant charging machine has been design to charge R134a, R22, R404A, R410A or other HCFC, HFC refrigerants and to be used in any type of cooling unit assembly line (water dispenser, refrigerator, freezer, heat pump etc.) performing evacuation, leak tests and refrigerant charges. Many advanced technologies such as CA-5AG movable plunger charging gun, resolution 1/10g precise ruby flowmeter, IDB intelligent double class balance cylinder, make the S4 series become industry standard products in terms of accuracy and stability.

S5

CACL-788C-S5 series high-speed refrigerant charging machine has been design to charge R22, R407C, R410A or other HCFC, HFC refrigerants and to be used in any type of cooling unit assembly line (central air-conditioning, commercial air conditioning, water chiller unit etc.) performing evacuation, leak tests and refrigerant charges. Thanks to CA-7AG high-speed charging gun, CA-CM4 efficient booster pump and ULVAC high power vacuum pump, the S5 series have greatly ascend than S4 series in vacuum rate, charging speed and volume. The fastest charging speed ≥180g/s, the biggest charging volume is 299,999g (Extensible) and the vacuum pump speed is 8L/S. S5 series keep the same charging precision with S4 series, both are the best precision in the world.

S6

CACL-788C-S6 series hydrocarbon refrigerant charging machine has been design to charge R600a, R290, R32 or other HC refrigerants and to be used in any type of cooling unit assembly line (water dispenser, refrigerator, air conditioning etc.) performing evacuation, leak tests and refrigerant charges. S6 series design with explosion-proof. Many years of technical experience accumulation and exquisite workmanship design achievement the S6 series of superior quality, MSA alarm system, ventilation and air pressure detection system, centralized control system make the equipment safety and reliable.

T6

CACL-788C-T6 series double charging system hydrocarbon refrigerant charging machine has been design to charge R600a, R290, R32 etc HC refrigerants and R134a, R404A, R410A or other HCFC, HFC refrigerants and to be used in any type of cooling unit assembly line (water dispenser, refrigerator, air conditioning etc.) performing evacuation, leak tests and refrigerant charges. T6 series design with explosion-proof, and can charging two kinds of refrigerants in one production line, For example, A gun charging R600a hydrocarbon refrigerant, B gun can charging R134a、R404A、R22 or other refrigerants. MSA alarm system, ventilation and air pressure detection system, centralized control system make the equipment safety and reliable.
